Section 1 of 5The Transistor as a Switch

3.4.3 Transistors

A small input voltage can control a larger current in an output circuit.

npn transistor
  • Has three connectionsthe base (input), the collector and the emitter.
MOSFET
  • An n-channel MOSFET has a gate (input), a drain and a source and acts in a similar way.
Switching on
  • The transistor turns on when the voltage at the base reaches about 0.7 V, allowing current between collector and emitter.
Switching off
  • Below that voltage the transistor stays off and no current flows in the output circuit.

Section 2 of 5Input, Process, Output

Electronic systems are described in three stages.

1
The input is a sensor such as a thermistor or LDR connected in a potential divider.
2
The sensor changes resistance with temperature or light, so the voltage at the divider output changes.
3
This voltage goes to the transistor, the process stage, which compares it with its switching value.
4
When the voltage is high enough the transistor turns on and current reaches the output device.
5
The output device, such as an LED, buzzer or motor, then operates.

Section 3 of 5Potential Divider Sensors

The position of the sensor in the divider decides when the voltage rises.

Potential Divider Sensors
Voltage share
  • The component with the larger resistance receives the larger share of the supply voltage.
Thermistor on top
  • As temperature rises the thermistor resistance falls, so the voltage across the lower resistor rises and the transistor switches on.
LDR on top
  • In bright light the LDR resistance is low, so the lower resistor has a higher voltage and the circuit switches on.
Swapping places
  • Reversing the positions of sensor and resistor makes the circuit respond when the temperature or light falls instead.
SensorConditionSensor resistanceVoltage across lower resistor
Thermistor (top)HotLowHigh, transistor on
Thermistor (top)ColdHighLow, transistor off

Section 4 of 5Worked Example

Question

  • A 6.0 V supply is connected to a thermistor and a 10 kΩ resistor in series.
  • The transistor input is across the 10 kΩ resistor and switches on at 0.7 V.
  • The thermistor is 90 kΩ when cold and 2.0 kΩ when hot.
  • Does the output operate in each case?

  1. Coldtotal resistance = 90 + 10 = 100 kΩ, so V across the 10 kΩ resistor = 6.0 × 10 ÷ 100 = 0.6 V.
  2. 0.6 V is below 0.7 V, so the transistor stays off.
  3. Hottotal = 12 kΩ, so V = 6.0 × 10 ÷ 12 = 5.0 V, which is above 0.7 V, so the transistor switches on.

Answer The output is off when cold (0.6 V) and on when hot (5.0 V).

Section 5 of 5Exam Checklist & Tips

3.4.3 – Key Points for the Exam

  • Transistor An electronic switch controlled by a small input voltage.
  • Base The input connection of an npn transistor.
  • Potential divider Two resistors in series that share the supply voltage in the ratio of their resistances.
  • Output device A component such as a lamp, buzzer or motor controlled by the transistor.

Common Mistakes

  • Saying the transistor switches on when the sensor resistance is high without checking the circuit layout.
  • Forgetting that the transistor only conducts when the input is above its switching voltage.
  • Mixing up the base and the collector connections.
  • Connecting the output device without a protective resistor where one is required.
