Section 1 of 6Spreadsheets for Calculations

Processing data by hand is slow and error-prone, so software is widely used.

Formulae
  • Formulae A formula in a cell calculates results automatically and updates when the raw data is corrected, which saves time and avoids copying errors.
Statistics
  • Statistics Built-in functions give the mean, standard deviation and range of a set of repeat readings in one step.
Unit columns
  • Unit columns Heading each column with its quantity and unit keeps calculations clear and prevents mixing cm³ with dm³.
Rounding
  • Rounding Keep full values in calculations and round only the final answer to the correct number of significant figures.

Section 2 of 6Graphing Software

Graphing Software
Scatter plots
  • Scatter plots These plot one measured variable against another and let a best-fit line or curve be added.
Trendlines
  • Trendlines Software fits linear, exponential or polynomial lines and reports the equation and R² value.
Linearising
  • Linearising Plotting ln k against 1/T turns a curved relationship into a straight line whose gradient gives useful constants.
Error bars
  • Error bars Error bars can be added from the uncertainty column, which shows how much a result may vary.

Section 3 of 6Databases and Modelling

1
Online databases give accepted values such as bond enthalpies, melting points and spectra for comparison with experiment.
2
Spectral databases let a measured IR or NMR spectrum be matched with a reference to help identify a compound.
3
Molecular modelling software builds three-dimensional structures and shows bond lengths, angles and shapes.
4
Simulations let variables such as temperature or concentration be changed quickly to test predictions safely.
5
Results from software must be compared with experiment because a model contains simplifying assumptions.

Section 4 of 6Using Software Well

Check the output
  • Check the output Inspect the graph and values for obvious errors, such as a point far from the trend that may come from a typing mistake.
Cite sources
  • Cite sources Record the origin and date of any database value, so readers can trace the data.
Choose the fit
  • Choose the fit A linear trendline should not be forced through data that is clearly curved, since this misrepresents the relationship.
Keep raw data
  • Keep raw data Store the original readings unchanged in a separate sheet before any processing.

Section 5 of 6Worked Example

Question

  • Five titres are 22.40, 22.50, 22.45, 22.55 and 22.60 cm³.
  • Find the mean and the sample standard deviation.

  1. Sum = 112.50 cm³, so mean = 112.50 ÷ 5 = 22.50 cm³.
  2. Deviations from the mean are −0.10, 0.00, −0.05, +0.05 and +0.10 cm³.
  3. Sum of squared deviations = 0.0250; divide by n − 1 = 4 to give 0.00625; the square root is 0.079 cm³.

Answer Mean = 22.50 cm³, standard deviation = 0.079 cm³

Section 6 of 6Exam Checklist & Tips

7.2.2 – Key Points for the Exam

  • Spreadsheet Software that stores data in cells and calculates results with formulae.
  • Trendline A line or curve fitted to data points by software.
  • Standard deviation A measure of how widely repeat readings are spread about their mean.
  • Simulation A computer model used to predict how a system behaves when variables change.
  • Linearising Changing variables so that a curved relationship plots as a straight line.

Common Mistakes

  • Rounding values in the middle of a calculation, which builds up rounding error in the final answer.
  • Trusting a high R² value as proof of a relationship when the data points are few or poorly chosen.
  • Forgetting to label axes and units in graphs made by software, as defaults are often missing.
  • Treating a database or simulation value as exact, without checking its source and conditions.
